Thunderbolt 4 USB4 Dock Pro | Good Way DBD1338
Good Way's DBD1338 Thunderbolt 4/USB4 Dock Pro delivers 96W PD, dual 4K/8K display support, and enterprise-grade connectivity for demanding workflows.
Thunderbolt™ 4 / USB4 Dock Pro (w/SD)
DBD1338
Customizable enterprise-grade docking station – Thunderbolt™ 4 –USB4 – Dual 4K monitors – SD4.0 – PD96W charging
The Thunderbolt™ 4/USB4 Dock Pro (w/SD) DBD1338 is a high-performance docking station designed to meet the needs of demanding workflows. Supporting both Windows and Mac systems, it is compatible with Thunderbolt 4, Thunderbolt 3, VESA Alternate Mode (MFDP), and USB4, offering versatility for a wide range of users.
Maximize Productivity with Thunderbolt 4 Technology
Maximize Productivity with Thunderbolt 4 Technology
Comprehensive Connectivity with Customization Options
The DBD1337 is equipped with diverse ports, including 2× USB-C 3.2 10G, 2× USB-A 3.2 10G, Hi-Res audio for headsets, and a 2.5GbE Ethernet port, ensuring maximum connectivity and efficiency. Additionally, its support for professional OEM and ODM services enables tailored solutions to meet specific customer needs.
Features
- The Thunderbolt™ 4/USB-C upstream port supplies 96W of laptop power, and two Thunderbolt 4/USB-C downstream ports
- The HDMI with DSC pass through supports up to 4K120HZ/8K30Hz resolution as specified in HDMI 2.1
- Supports up to two 4K-resolution displays or one 8K-resolution displays for content extension
- Conveniently connect USB devices with 2× USB-A 10G and 2× USB-C 10G ports
- Built-in 2.5Gbe Ethernet enhance networking stability
- The audio combo jack to headphone for conferencing or video-watching applications
Connection Technology
- USB4
- USB 3.0
- USB-C
- Thunderbolt 3
- Thunderbolt 4
Data Port
- USB-A
- USB-C
Hubs by Connection to Host
- USB-C
Input port
- USB-C
Video Output
- USB-C
- HDMI
Ethernet Port
- 1Gbps
- 2.5Gbps
Max Display
- 2
Max Resolution
- 2K@60
- 4K@30
- 4K@60
- 4K@120
- 8K@30
Max Power Output
- 96W
Power Mode
- Self-Power
Power Delivery
- YES
Audio in
- NO
SD Card Reader
- NO
Ports for Charging
- USB-C
Specifications
| Model | DBD1338 |
|---|---|
| Description | Thunderbolt™ 4 / USB4 Dock Pro (w/SD) |
| Thunderbolt Upstream | 1 |
| Thunderbolt Downstream | 2 |
| USB Downstream | 2× USB-A 10G 2× USB-C 10G |
| Legacy Video Port | 1x HDMI2.1 |
| Max Display | 1× 8K30Hz / 2× 4K60Hz |
| LAN | 1× RJ45 (2.5GbE) |
| Audio Jack | 1× 3.5mm TRRS |
| SD Card | 1× SD4.0 |
| PD | PD96W |
| PD Supply | DC 150W |
- Product Images
Thunderbolt™ 4 USB4 Dock Pro SD_DBD1338_05
